Cummins CM1881 ACM Bench Cable
Product specification
| Manufacturer | CreativeOBD |
|---|---|
| Product type | Bench Cables |
| Tool | DFOX |
Product details
CreativeOBD bench cable for Cummins CM1881 aftertreatment control modules (ACM). Provides a direct connection at the module’s external connector for supported diagnostics and programming on the bench in bench mode.
Module and applications
The CM1881 controls exhaust aftertreatment / SCR and AdBlue functions and is separate from the main engine ECU. Applications include selected DAF XF105/XF106 and Kenworth vehicles with 10.8-litre or 12.9-litre PACCAR engines.
Confirm the complete module identification, connector, and pinout before ordering. Vehicle model and engine size alone do not establish compatibility.
Cable details
- Dedicated CM1881 module connection.
- Tool-end termination supplied to match the selected product option.
- Hand-assembled and continuity-tested in the UK by CreativeOBD.
Connection and compatibility
Select the connection version required for your programming interface from the product options. Where an OBD option is offered, this refers to the cable’s interface connector for bench use.
Supported operations depend on the exact module, programming interface and software licence. Follow the equipment manufacturer’s current connection instructions, including supply voltage, polarity and any additional connections required. Boot/JTAG access may require separate equipment.
Supplied: one CM1881 bench cable in the selected version. Programming interface, power supply, and software licences are not included.
